Pipe SlideFPL-PS-S257
Series 257 Pipe Slide Support Assembly - 1" to 24"
Series 257 low-friction graphite composite pipe slide for 1"-24" NPS horizontal pipe runs. Allows controlled axial thermal movement while supporting pipe weight.
Applications
- Thermal Expansion Systems
- Steam Distribution
- Hot Water Piping
- Industrial Process Lines
- HVAC Mechanical Rooms
Starting at
$340.00
Price varies by size and configuration — contact for quote
Engineering Data
- Size Range
- 1" – 24" NPS
- Bearing Type
- Graphite Composite (low friction)
- Axial Travel
- 4" or 10" axial
- Construction
- Carbon Steel, Red Oxide Primer
- Mounting Type
- Type 1 Weld Base or Type 3 Bolt-Down
- Standards
- ASME B31.1, B31.3, MSS SP-58, Buy American Act
- Lead Time
- 3–5 Business Days
We respond to all RFQs within 1 business day
