Seismic V-Loop – Copper Sweat – 2″ Movement

Price range: $224.89 through $2,450.49

Multi-axis Seismic V-Loop with copper sweat ends; nominal 2-inch movement class with X/Y/Z motion capability. 321SS/304SS braided construction. Maximum published temperature 400°F; ratings vary by size.

SKU: FPL-VL-SWT-2M Category:

Description

The Seismic V-Loop with copper sweat ends is a multi-axis flexible piping assembly for thermal expansion and seismic displacement. The controlled product specification identifies allowable motion in the X, Y, and Z axes and a nominal 2-inch movement class.

Construction uses 321 stainless steel corrugated hose with 304 stainless steel single braid, factory-welded components, a support bracket, and a drain plug. The maximum published operating temperature for this end configuration is 400°F. Working pressure, test pressure, dimensions, spring force, and available pipe sizes vary by selected size.

Use only after application review for pressure, temperature, media, movement direction, support geometry, anchors, guides, installation clearance, and applicable code requirements. NSF 372 is listed in the source product data; certification documentation and applicability to the selected configuration should be confirmed during order review.

Additional information

WeightN/A
DimensionsN/A
Pipe Size (NPS)

1/2", 3/4", 1", 1-1/4", 1-1/2", 2", 2-1/2", 3", 4"
