316SS Double-Braided Metal Hose Assembly — 150# Flange x 150# Flange

Description

The 316SS Double-Braided Metal Hose Assembly – 150# Flange x 150# Flange is engineered for corrosive flanged piping systems requiring vibration isolation, controlled movement, or flexible equipment connections. The corrugated hose and double braid are manufactured from 316 stainless steel.

Key Features

• 316 stainless steel corrugated hose core
• Double 316 stainless steel braid reinforcement
• Class 150 raised-face flanges on both ends
• Configurable hose ID and overall length
• Overall length from 12"–240" in 0.5" increments
• Engineering review before fabrication

Applications

Typical uses include chemical and process piping, pump connectors, heat exchangers, chillers, packaged equipment, water or glycol systems, and other corrosive-service applications compatible with the selected assembly materials. Steam service is not the default application path for this Class 150 product; use the approved steam-service selection path or submit the operating conditions for engineering review.

Engineering Review

Class 150 identifies the flange class; it is not the direct PSI rating of the completed metal-hose assembly. Final suitability depends on hose ID, validated working-pressure data, temperature, media, movement, minimum bend radius, flange material, support conditions, and installation geometry. Flanges must be aligned without forcing the hose into torsion.

Ordering Notes

Select hose ID and overall length. Every order is reviewed before fabrication. Alternate flange materials, Class 300 flanges, special cleaning, pressure testing, tagging, material certificates, and documentation packages are available through RFQ.
